產品特色
UVA LED穿透力強，壽命長、效率高。適用於固化、曝光
UVB LED 能量適中，可促進維生素D合成，用於皮膚治療
UVC LED短波長、高能量，適合強效殺菌消毒
產品列表
UVA
| Model Name | Dimension / View Angle | Peak wavelength | Test Current / Max Current | Vf | Radiant flux |
|---|---|---|---|---|---|
|
PU35AH2 V0
|
3.5*3.5*2.83 mm / 60° | 365 nm | 700/1500 mA | 3.4-3.8 V | 1000 mW |
|
PU35AH2 V1
|
3.5*3.5*1.5 mm / 120° | 385/395/405 nm | 700/2000 mA | 3.2-3.8 V | 1200 mW |
|
PU35AH3 V0
|
3.5*3.5*2.83 mm / 60° | 365 nm | 500/700 mA | 3.0- 4.0 V | 650 mW |
|
PU35AH3 V2
|
3.5*3.5*1.5 mm/ 120° | 385/395/405 nm | 500/700 mA | 3.0-4.0 V | 750 mW |
|
PU35AH3 V1
|
3.5*3.5*2.83 mm / 60° | 365 nm | 500/1000 mA | 3.4-3.8 V | 680 mW |
|
PU35AH3 V3
|
3.5*3.5*1.5 mm / 120° | 385/395/405 nm | 500/1500 mA | 3.2-3.8 V | 850 mW |
|
PU68AH1 V0
|
6.5*6.5*4.95 mm / 60° | 365 nm | 1000/2000 mA | 6.4-7.2 V | 3000 mW |
|
PU68AH1 V1
|
6.5*6.5*1.49 mm / 120° | 385/395/405 nm | 1000/3000 mA | 6.2-7.0 V | 3400 mW |
|
PU68AH1 V2
|
6.5*6.5*4.95 mm /60° | 365 nm | 500/1000 mA | 13.2-14.8 V | 3000 mW |
|
PU68AH1 V3
|
6.5*6.5*1.49 mm / 125° | 385/395/405 nm | 500/1500 mA | 12.4-14.4 V | 3400 mW |
|
PU88S11 V0
|
3.5*3.5*2.1 mm / 125° | 365 nm | 350/350 mA | 3.4- 3.8 V | 500 mW |
|
PU88S04 V0
|
3.5*3.5*2.1 mm / 125° | 405 nm | 350/700 mA | 3.0-3.5 V | 600 mW |
|
PU88S01 V0
|
3.5*3.5*2.1 mm / 125° | 365 nm 385/395/405 nm | 500/700 mA 500/700 mA | 3.4-4.0 V 3.2-3.8 V | 850 mW 950 mW |
|
PU35AH3 V4
|
3.5*3.5*1.5 mm / 125° | 365 nm 385/395/405 nm | 500/700 mA 500/700 mA | 3.2-3.8 V 3.2-3.8 V | 850 mW 950 mW |
|
PU35AH3 V5
|
3.5*3.5*1.5 mm / 125° | 365 nm | 500/700 mA | 3.2-3.8 V | 850 mW |
|
PU21S31 V0
|
2.0*1.6*0.7mm / 110° | 365 nm | 20/40 mA | 3.0-4.0 V | 21 mW |
|
PU28AM1 V0
|
3.5*2.8*1.65 mm / 120° | 405 nm | 150/150 mA | 3.2-3.8 V | 200 mW |
|
PU28AM2 V0
|
3.5*2.8*1.65 mm / 120° | 365/395 nm | 150/150 mA | 3.0- 3.4 V | 200 mW |
UVB
| Model Name | Dimension / View Angle | Peak wavelength | Test Current / Max Current | Vf | Radiant flux |
|---|---|---|---|---|---|
|
PU35BL1 V0
|
3.5*3.5*1.6 mm /120° | 305-315 nm | 20/40 mA | 5-6.5 V | 4 mW |
|
PU35BL2 V0
|
3.5*3.5*1.6 mm /120° | 305-315 nm | 40/80 mA | 5-6.5 V | 8 mW |
|
PU35BM1 V0
|
3.5*3.5*1.6 mm /120° | 305-315 nm | 100/150 mA | 5-6.5 V | 24 mW |
|
PU35BM1 V1
|
3.5*3.5*2.5 mm /60° | 305-315 nm | 100/150 mA | 5-6.5 V | 24 mW |
|
PU35BM2 V0
|
3.5*3.5*1.6 mm /120° | 305-315 nm | 200/300 mA | 5-6.5 V | 24 mW |
|
PU35BM2 V1
|
3.5*3.5*2.5 mm /60° | 305-315 nm | 200/300 mA | 5-6.5 V | 24 mW |
|
PU35BH1 V0
|
3.5*3.5*1.6 mm /120° | 280-290 nm 290-300 nm 300-310 nm | 350/500 mA | 5-6.5 V | 90 mW 90 mW 80 mW |
|
PU35BH1 V1
|
3.5*3.5*2.5 mm /60° | 280-290 nm 290-300 nm 300-310 nm | 350/500 mA | 5-6.5 V | 90 mW 90 mW 80 mW |
UVC
| Model Name | Dimension / View Angle | Peak wavelength | Test Current / Max Current | Vf | Radiant flux |
|---|---|---|---|---|---|
|
NEW
PU35CH1 V0
|
3.5*3.5*1.6 mm /125° | 275 nm | 350/500 mA | 5.0 - 6.5 V | 100 mW |
|
PU68CH1 V0
|
6.8*6.8*1.83 mm /125° | 275 nm | 500/600 mA | 5.0-6.5 V | 80 mW |
|
PU35CM1 V3
|
3.5*3.5*1.72 mm / 125° | 275 nm | 100/150 mA | 5.0 - 6.5 V | 26 mW |
|
PU35CM1 V6
|
3.5*3.5*2.95 mm / 60° | 275 nm | 100/150 mA | 5.0 - 6.5 V | 26 mW |
|
PU35CM1 V7
|
3.5*3.5*3.25 mm / 30° | 275 nm | 100/150 mA | 5.0 - 6.5 V | 26 mW |
|
PU35CM1 V8
|
3.5*3.5*1.6 mm / 125° | 275 nm | 100/150 mA | 5.0 - 6.5 V | 26 mW |
|
NEW
PU35CM1 V9
|
3.5*3.5*1.6 mm / 125° | 275 nm | 150/180 mA | 5.0 - 6.5 V | 55 mW |
|
PU35CM7 V1
|
3.5*3.5*1.6 mm / 125° | 275 nm | 200/300 mA | 5.0 - 6.5 V | 52 mW |
|
PU35CL1 V2
|
3.5*3.5*1.6 mm / 125° | 275 nm | 20/30 mA | 5.0 - 6.5 V | 3.5 mW |
|
PU35CL1 V3
|
3.5*3.5*1.6 mm / 125° | 275 nm | 40/60 mA | 5.0 - 6.5 V | 8 mW |
|
PU35CL1 V4
|
3.5*3.5*1.6 mm / 125° | 275 nm | 40/40 mA | 5.0 - 6.5 V | 10 mW |
