產品特色
提供一站式且技術力雄厚的 LED方案，並且具備強大的整合能力
具價格競爭力的消費性電子 LED 方案供應商
提供從設計至交付的高效率服務
產品列表
Top View
| Model Name | Backlight | Color | Dimension | Brightness | Beam angle |
|---|---|---|---|---|---|
|
PT40A6P.2
|
Monitor | white | 4.0*1.4 mm | 38lm @100mA | 120° |
|
PT40W43.1
|
Monitor | white | 4.0*1.4 mm | 23.5lm @60mA | 120° |
|
PT41A12.1
|
Monitor | white | 4.0*1.2 mm | 24lm @60mA | 120° |
|
PT40A7S.1
|
Monitor | white | 4.0*1.4 mm | 43.9lm @60mA | 120° |
|
PT40A76.1
|
Monitor | white | 4.0*1.4 mm | 24lm @60mA | 120° |
|
PT40Z39.0
|
Industrial / PID | white | 4.0*1.4 mm | 85lm @ 120mA | 120° |
|
PT40A7B.0
|
Industrial / PID | white | 4.0*1.4 mm | 24lm @60mA | 120° |
|
PT30Z84.0
|
TV | white | 3.0*3.0 mm | 180lm @ 600mA | 120° |
|
PT35B39.4
|
TV | Blue | 3.5*2.8 mm | 100mW @ 30mA | 120° |
|
PT30BAR.0
|
TV | Blue | 3.0*3.0 mm | 3010mW @ 220mA | 120° |
|
PT16Z09.0
|
TV | white | 1.6*1.6 mm | 290lm @ 400mA | 145° |
|
PT13Z14.0
|
TV | white | 1.3*1.3 mm | 260lm @ 750mA | 142° |
|
PT13Z16.0
|
TV | white | 1.3*1.3 mm | 310lm @ 750mA | 142 |
|
PT17Z00.0
|
TV | white | 1.7*0.7 mm | 80lm @100mA | H140/V170 |
Side View
| Model Name | Backlight | Color | Dimension | Brightness | Beam angle |
|---|---|---|---|---|---|
|
PS06W12.2
|
Industrial / PID | white | 3.8*0.6 mm | 8.75lm @ 20mA | 120° |
|
PS06W43.0
|
Industrial / PID | white | 3.0*0.6 mm | 8.38lm @ 20mA | 120° |
|
PS06W14.0
|
Industrial / PID | white | 3.8*0.6 mm | 8.1lm @ 20mA | 120° |
|
PS04A4T.0
|
e-book | white | 3.0*0.6 mm | 8.2lm @20mA | 120° |
|
PS04W4S.0
|
e-book | white | 3.0*0.6 mm | 3322mcd@20mA | 120° |
|
PS04Z4R.0
|
e-book | white | 3.0*0.6 mm | 3322mcd@20mA | 120° |
|
PS04A54.0
|
e-book | white | 3.0*0.6 mm | 7.25lm @20mA | 120° |
|
PS06A6X.1
|
Laptop | white | 3.0*0.6 mm | 8.3lm @20mA | 120° |
|
PS06A6X.2
|
Laptop | white | 3.0*0.6 mm | 8.3lm @20mA | 120° |
|
PS06W12.4
|
Laptop | white | 3.8*0.6 mm | 9.25lm @20mA | 120° |
|
PS06W24.1
|
Laptop | white | 3.8*0.6 mm | 9.25lm @20mA | 120° |
|
PS06Z68.0
|
Laptop | white | 3.8*0.6 mm | 8.25lm @20mA | 120° |
