產品特色
低藍光,高顯指全頻譜護眼方案
節律照明最優化MP (Melanopic/Photopic) Ratio，提供高光效方案
產品列表
Eye Care
| Model Name | Dimension | Test Current / Max Current | CCT / Ra | Vf | Luminance flux |
|---|---|---|---|---|---|
|
PC30V21 V0
|
3*1.4*0.65 mm | 65 / 150 mA | 5000K / Ra>90 | 2.7~3.0 V | 22~28 lm |
|
PC40V07 V2
|
4*1.4*0.65 mm | 60 / 150 mA | 5000K / Ra>95 | 2.7~3.0 V | 22~28 lm |
|
PC35U16 V6
|
3.5*2.8*0.7 mm | 65 / 200 mA | 5000K / Ra>95 | 2.7~2.9 V | 26~30 lm |
|
PC40V07 V1
|
4*1.4*0.65 mm | 30 / 100 mA | 5000K / Ra>95 | 5.2~5.8 V | 24~30 lm |
|
PC35V43 V2 (low blue light)
|
3.5*2.8*0.7 mm | 100 / 120 mA | 5000K / Ra>95 | 8.5~9.1 V | 100~120 lm |
|
PC35V43 V0 (low blue light)
|
3.5*2.8*0.7 mm | 150 / 160 mA | 5000K / Ra>95 | 5.8~6.4 V | 90~110 lm |
|
PC33V67 V0
|
3*3*0.67 mm | 150 / 240 mA | 5000K / Ra>95 | 5.8~6.4 V | 100~130 lm |
節律照明
| Model Name | Dimension | Test Current / Max Current | CCT / Ra | Vf | Luminance flux |
|---|---|---|---|---|---|
|
PC33U56 V1_DAY_450nm
|
3*3*0.67 mm | 150 / 200 mA | 5000K / Ra>90 | 5.8~6.4 V | 120~150 lm |
|
PC33U56 V1_DAY_480nm
|
3*3*0.67 mm | 150 / 200 mA | 5000K / Ra>90 | 5.8~6.4 V | 100~130 lm |
|
PC33U56 V1_NITE
|
3*3*0.67 mm | 150 / 200 mA | 2700K / Ra>90 | 5.8~6.4 V | 100~130 lm |
